Specifikationer
| Driver | 18” (460mm)/4” (100mm) voice coil, long excursion, ferrite magnet, waterproof cone |
| Frekvans område | 47Hz – 150Hz ±3dB, -10dB @ 41Hz |
| Følsomhed | -20dBu for 100dB SPL (CDD12/15 pre-set) -13dBu for 100dB SPL (CDD8 pre-set) |
| MAX SPL | 132dB continuous / 135dB peak |
| Input interface | Female XLR input, male XLR link output, Dante Audio Neutrik® Ethercon |
| Analog input impedans | 20 kΩ balanced to ground |
| Maximum analog input niveau | 24.6 Vpp (+21dBu), over voltage protected |
| Konnektorer | 2 x Neutrik® Ethercon |
| Netværk interfce | TCP/IP and UDP/IP |
| Forstærker | 2 channel switch-mode, class D, Bridged Tied |
| Power amp max | 2000W total |
| Normal forbrug | 550W |
| Mål | B: 600mm x H:507mm x D: 632mm (760mm including castors) |
| Vægt | 46,5Kg. |
